The Ultimate Maintenance Guide: How to Protect Your Coil Winding Machine During Holidays & Downtime

Introduction: The Silent Killer of Precision

As the global manufacturing sector slows down for the holidays, one overlooked step often determines the efficiency of the post-holiday restart: Scientific Machine Shutdown.

Many people think shutting down is just turning off the power, but for modern precision winding equipment, that is far from enough. Improper shutdown allows humidity, dust, and residual stress to become "silent killers", leading to accuracy loss, unexpected alarms, or even rust on core components when you restart.

To address this, the SIPU Technical Team has condensed their extensive Operation & Maintenance Manual into an actionable "Equipment Health Checklist."

Tip 1: Deep Cleaning – Beyond the Surface

Cleaning is not just wiping. The SIPU manual highlights that micron-level copper dust and wire enamel wax can invade critical areas.

• Action: Before the holiday, use dry compressed air to blow out the Tensioner Magnetic Wheels and Nozzle Tips specifically.

• Why: This prevents wax/dust from hardening over time, which would affect tension stability and wire feeding smoothness upon restart.

• (💡 Pro Tip: If you notice grooves on your Nozzles or Tension Arms during cleaning, order replacements now to avoid delays in February!)

Tip 2: Lubrication is "Isolation"

Lubrication is not just for movement; it forms a protective film to isolate oxygen and moisture.

• Action: Apply specified Lithium-based Grease (or ISO VG68 oil) to core moving parts like Linear Guide Rails and Ball Screws.

• Crucial Step: After applying, manually move the axes back and forth 3-5 times. This ensures the oil film covers the entire track, preventing rust spots caused by humid holiday air.

Tip 3: Electrical & Pneumatic "Silent Mode"

Simply turning off the key switch is not safe enough for a long break.

• Electrical: Cut off the Main Circuit Breaker. This completely isolates sensitive circuits, such as Servo Drivers and PLCs, from potential grid surges or lightning strikes.

• Pneumatic: Drain the water from the Air Filter Regulator (FRL) and release residual pressure in the pipes. This allows the cylinder seals to "rest" in a stress-free state.

Tip 4: The "Warm-Up Philosophy" for Restart

Rushing to run at full speed (e.g., 18,000 RPM) immediately after the holiday is a major mistake.

• Action: SIPU’s protocol emphasizes running the machine in a Low-Speed "Warm-up Mode" for 10-15 minutes upon restart.

• Why: Just like an athlete warming up, this allows the cold, thickened grease to redistribute evenly, preventing dry grinding damage to bearings and guides.

Tip 5: Quick Troubleshooting Guide (Bonus)

To help you further, here is a quick reference for common post-holiday issues:

Beyond the Manual: SIPU's Commitment to Lifetime Support

While we don't have a complex "Escort Plan," we do have a simple promise: We are always here when you need us.

SIPU provides comprehensive remote technical guidance for all our clients. Whether via video conference or instant messaging, our engineering team is ready to guide your staff through the shutdown and restart procedures to prevent any operational risks.SIPU doesn't just sell machines; we promise to safeguard the long-term value of our clients' production assets. This public guide is just a glimpse of our expertise.

For specific issues, our team is just a call away.

📥 Exclusive Resource Access

Note: The full version of the SIPU Equipment Operation & Maintenance Manual (PDF) contains proprietary technical details and is available exclusively for SIPU clients.

How to get it: Please contact your dedicated sales representative or email sales@sipuglobal.com with your machine serial number. We will send the digital manual directly to your inbox.

❓ Frequently Asked Questions (FAQ)

Q1: What specific type of oil should I use for the guide rails?

A1: For SIPU winding machines, we generally recommend ISO VG68 Guide Way Oil or 0# Lithium-based Grease. Please avoid using light oils like WD-40 for lubrication, as they evaporate quickly.

Q2: How long should I run the "Warm-up Mode" after the holiday?

A2: We suggest running the machine at low speed (10%-20%) for at least 10 to 15 minutes. This allows the grease to soften and distribute evenly across the bearings and screws before full-speed production.

Q3: Do I need to remove the PLC battery during long shutdowns?

A3: Generally, no. However, if the machine will be powered off for more than 3 months, we recommend checking the battery status upon restart. A low battery might cause the loss of stored winding programs, so backing up data to a USB drive is always a good practice.

Q4: Which spare parts should I stock up on before the holiday?

A4: It is wise to keep a stock of consumables. We recommend ordering extra Winding Nozzles (Ruby/Carbide), Wool Felts, and Tension Springs. These parts are low-cost but critical for quality; having them on hand prevents shipping delays when you restart.

Q5: Can SIPU provide video guidance if we encounter issues during restart?

A5: Yes, absolutely. If you face any alarms or mechanical issues upon restarting, please contact us immediately. Our engineers can provide real-time troubleshooting via Video Call (WhatsApp/WeChat) to get your production line back up and running quickly.
